Burndy YAEV10-T4 Box Insulug Nylon Insulated Ring Tongue Terminal, 12-10 Wire Range, 0.56" Width, 0.35" Length, 3/8 Stud Size (Pack of 50)

Color: Yellow

Features:

• Provides maximum reliability and electrical capacity plus an extra strong terminal tongue
• Manufactured from one-piece pure electrolytic copper
• Provides high conductivity, low resistance with no seams to split plus ductility for excellent crimp forming properties
• Electro-tin plated
• Nylon insulation is locked in place

PartNumber: YAEV10-T4 BOX

Details: The Insulug type YAEV is designed for very demanding high vibration applications encountered in aircraft and aboard ships as well as motor lead applications in hospitals, industrials and generating plants. The nylon insulated seamless, electrolytic copper barrel with double thick tongue provides an extra strong insulated connection. The terminal is rated 105 degrees C and meets SAE-AS7928 requirements. Double thick tongue. Provides maximum reliability and electrical capacity plus an extra strong terminal tongue. Manufactured from one-piece pure electrolytic copper. Provides high conductivity, low resistance with no seams to split plus ductility for excellent crimp forming properties. Electro-tin plated. Provides long-lasting corrosion resistance. Nylon insulation is locked in place. Insulation will not move or twist off. 30volt nylon insulation. High dielectric strength and stability in demanding oily environmental conditions. Color Coded. Provides quick, easy wire size connector selection.

UPC: 781810023068

EAN: 0781810023068

Model: YAEV10-T4 BOX

Item Condition: New
